Non-return throttle valve, threaded, made of plastic:
- banjo with threaded connections
- with recessed screw for throtteling supply air
- reliable and progressive adjustment with a screwdriver guaranteeing stability of adjustment
- strong construction for improved longevity
- for use in all pneumatic installations due to their high performance capability and small size
- banjo with threaded connections
- with recessed screw for throtteling supply air
- reliable and progressive adjustment with a screwdriver guaranteeing stability of adjustment
- strong construction for improved longevity
- for use in all pneumatic installations due to their high performance capability and small size
| Maximum working pressure in bar: | 10 |
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Engineered polymer |
| Material body 2: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| max. temperature in °C: | 70 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,019 |
