Banjo with recessed screw and threaded connections:
- reliable and progressive adjustment with a screwdriver guaranteeing stability of adjustment
- strong construction for improved longevity
- for use in all pneumatic installations due to their high performance capability and small size
- reliable and progressive adjustment with a screwdriver guaranteeing stability of adjustment
- strong construction for improved longevity
- for use in all pneumatic installations due to their high performance capability and small size
| Maximum working pressure in bar: | 10 |
| Material seal: | NBR |
| Material adjusting spindle: | Brass nickel plated |
| Material body: | Engineered polymer |
| Material body 2: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| max. temperature in °C: | 70 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,006 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
Available downloads:
3D Modell
