In line connection of tubing to a threaded port. It is mounted from the outside. Very solid construction and sealing of tube by 2 O rings. manual connection and disconnection with a flat spanner to secure gripping of tube.Individual unit quality control and dating in order to guarantee quality and traceability. Complies RoHS.
| Maximum working pressure in bar: | 60 |
| Material seal: | NBR |
| Material body: | Brass |
| Material release button: | Brass |
| min. temperature in °C: | -40 |
| max. temperature in °C: | 120 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,021 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
