Full-flow self-cleaning ball maintains the cleanliness of the circuit
Carstick connection providing resistance to water hammer
Inert technical polymer providing the best mechanical strength, thermal and chemical resistance
FDA, NSF 51, meet WQA (Water Quality Association) requirements.
Maximum working pressure in bar: | 10 |
Material seal: | EPDM |
Material body: | Polypropylene with glass fibers |
Material lever: | Polyamide |
Material stem: | Polysulfone |
Material toothed washer: | Stainless steel |
min. temperature in °C: | -15 |
max. temperature in °C: | 100 |
RoHS compliant: | Yes |
Weight in kg: | 0,015 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
