3614 - Male stud couplings

LF 3600 - Brass special - Industrie and food, Male stud couplings, Brass nickel plated chemical fda brass

From €7.32 *

Available, delivery time:

Product name	C	E	ØD	F	H	Price		Quantity
3614 04 10 Male stud coupling	G1/8"	7,5	4 mm	14	25	€7.32	Available, delivery time: 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 04 13 Male stud coupling	G1/4"	11	4 mm	17	29	€9.77	Available in 15 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 04 19 Male stud coupling	M5x0,8	5	4 mm	10	22	€10.17	Available in 40 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 06 10 Male stud coupling	G1/8"	7,5	6 mm	14	27,5	€7.38	Available in 10 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 06 13 Male stud coupling	G1/4"	11	6 mm	17	31,5	€10.21	Available, delivery time: 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 08 10 Male stud coupling	G1/8"	9,5	8 mm	15	28,5	€9.52	Available in 15 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 08 13 Male stud coupling	G1/4"	13,5	8 mm	17	32,5	€11.47	Available in 5 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 10 17 Male stud coupling	G3/8"	14	10 mm	22	38	€18.17	Available, delivery time: 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 12 17 Male stud coupling	G3/8"	14	12 mm	22	39	€25.34	Available in 15 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3614 12 21 Male stud coupling	G1/2"	18,5	12 mm	24	43,5	€27.37	Available in 15 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.

Product information "3614 - Male stud couplings"

In-line connection of tubing to a threaded port. Solid construction and compact design. Excellent resistance to corrosion. Individual unit quality control and dating in order to guarantee quality and traceability. Components meet FDA standard and 1935/2004/EC regulation and comply RoHS.

Material:	Brass nickel plated chemical fda brass
max. temperature in °C:	150
min. temperature in °C:	-20
RoHS compliant:	Yes
Vacuum resistance in mm Hg:	755
Material seal ring:	Brass nickel plated chemical fda brass
Material seal:	FKM
Material body:	Brass nickel plated chemical fda brass
Material release button:	Brass nickel plated chemical fda brass

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
