3603 - Stud run tee

LF 3600 - Brass special - Industrie and food, Stud run tee, Brass nickel plated chemical fda brass

From €12.08 *

Available, delivery time:

Product name	C	ØD	F	G	H	H1	J	L	Price		Quantity
3603 04 10 L-stud coupling	R1/8"	4 mm	10	10	19,5	18	7	23	€12.08	Available in 30 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 06 10 L-stud coupling	R1/8"	6 mm	13	12	23,5	21,5	8	28	€13.17	Available in 20 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 06 13 L-stud coupling	R1/4"	6 mm	14	12	24,5	21,5	8	28	€14.22	Available in 20 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 08 10 L-stud coupling	R1/8"	8 mm	14	15	25	23,5	10	31	€13.70	Available in 20 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 08 13 L-stud coupling	R1/4"	8 mm	14	15	26,5	23,5	10	31	€14.40	Available in 20 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 10 13 L-stud coupling	R1/4"	10 mm	18	17,5	30,5	29	12	37,5	€23.90	Available in 40 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 10 17 L-stud coupling	R3/8"	10 mm	18	17,5	32,5	29	12	37,5	€28.05	Available in 30 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 12 17 L-stud coupling	R3/8"	12 mm	20	19,5	36,5	31	15	40,5	€30.51	Available in 40 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.
3603 14 21 L-stud coupling	R1/2"	14 mm	22	21,5	40	34	16	45	€37.69	Available in 30 days, transport time 1-2 working days	Product Quantity: Enter the desired amount or use the buttons to increase or decrease the quantity.

Product information "3603 - Stud run tee"

In line connection of 2 tubes at a 90° angle to a threaded port. Solid construction and compact design. Excellent resistance to corrosion. Individual unit quality control and dating in order to guarantee quality and traceability. Components meet FDA standard and 1935/2004/EC regulation and comply RoHS.

Special feature:	schwenkbar
Material:	Brass nickel plated chemical fda brass
max. temperature in °C:	150
min. temperature in °C:	-20
RoHS compliant:	Yes
Vacuum resistance in mm Hg:	755
Material seal ring:	Brass nickel plated chemical fda brass
Material seal:	FKM
Material body:	Brass nickel plated chemical fda brass
Material threaded fitting:	Brass nickel plated chemical fda brass
Material release button:	Brass nickel plated chemical fda brass

All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
