In line connection of tubing to a threaded port in very tight spaces. Tightened with an Allen key. solid construction, aesthetic and unobtrusive for a better connection. Full air flow. Individual unit quality control and dating in order to guarantee quality and traceability. Complies RoHS and ISO 14743.
| Maximum working pressure in bar: | 18 |
| Material seal ring: | PTFE |
| Material seal: | NBR |
| Material body: | Brass nickel plated |
| Material release button: | Brass nickel plated |
| min. temperature in °C: | -15 |
| max. temperature in °C: | 70 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,001 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
