Product information "321K4606 Solenoid valve without coil"
The K-series pilot operated solenoid valves were specifically developed for the demanding conditions of industrial, process engineering, and transportation applications. A key quality feature is the robust stainless steel actuator, designed for an extremely long service life of several million switching cycles, thus reducing long-term total cost of ownership even in intensive heavy-duty applications. The series also impresses with its ease of maintenance, which is particularly emphasized in the Red Ring 321K series by an innovative side-mounted diaphragm design. Thanks to a comprehensive selection of electrical components with international certifications such as VDE, UL, and ATEX, these valves can be flexibly deployed in challenging environments. Applications range from precise gas and liquid control, compressors, and air treatment to the reliable regulation of water, steam, or specialized systems such as urea heating.
Connection:
Female thread 3/4"
Seal:
FKM
Function:
normally closed
Weight in kg:
0,585
Material:
Brass
Bore in mm:
18
Actuation:
pre-controlled
Series:
Lucifer
Working temperature:
-10°C to +100°C fluid temperature
Flow rate in l/min:
100
Power in W:
8
Operating pressure differential max. in bar:
12
Case:
Assembly kit 2995
Professional recommendation:
Fast delivery programm
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
