Connection of tubing at a 90° angle. Designed to limit constrictions in the tubing diameter when the cylinder is operating. Precoated thread ensuring direct sealing and full air flow. Complies RoHS and ISO 14743.
Seal coating:
PTFE
Weight in kg:
0,08
Maximum working pressure in bar:
20
max. temperature in °C:
80
min. temperature in °C:
-20
RoHS compliant:
Yes
Vacuum resistance in mm Hg:
755
Material seal:
NBR
Material body:
Engineered polymer
Material threaded fitting:
Brass nickel plated
Material gripping ring:
PTFE
Material toothed washer:
Stainless steel
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
