Dient der Druck- oder Durchfluss-Verteilung auf vier tubee. Can be fixed in position by the use of two screws. solid construction. Full air flow. Individual unit quality control and dating in order to guarantee quality and traceability.Complies RoHS and ISO 14743.
| Material seal: | NBR |
| Material body: | Engineered polymer |
| Material threaded fitting: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 80 |
| Vacuum resistance in mm Hg: | 755 |
| Material: | Engineered polymer |
| Special feature: | schwenkbar |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
