Product information "1809 06 22 Single banjo elbow connection"
Single banjo elbow connection between tube and male thread. Stainless steel AISI 316 L, offers excellent resistance to aggressive fluids and corrosive environments. Available from 6 to 16 mm o.d..
Weight in kg:
0,071
Maximum working pressure in bar:
80
max. temperature in °C:
250
min. temperature in °C:
-60
RoHS compliant:
Yes
Material body:
Stainless steel 316l
Material gripping ring:
Stainless steel 316l
Material union nut:
Stainless steel 316l
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
