Protection springs to prevent the ends of the tubing from becoming damaged. Very small bend radius and high resistance to abrasion.
| Seal coating: | PTFE |
| Material seal: | NBR |
| Material spring: | Treated steel |
| Material body: | Brass nickel plated |
| Material toothed washer: | Stainless steel |
| min. temperature in °C: | -15 |
| max. temperature in °C: | 70 |
| Material: | Brass nickel plated |
| RoHS compliant: | Yes |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
