Connected to a pressure gauge or hydrometer, used for opening or closing a fluid system and thus measuring connection/disconnection of the device. A locking pin can be used to enable the gauge to be fitted permanently.
| Maximum working pressure in bar: | 10 |
| Material seal: | NBR |
| Material body: | Brass nickel plated |
| Material lever: | Stainless steel |
| min. temperature in °C: | -20 |
| max. temperature in °C: | 100 |
| RoHS compliant: | Yes |
| Weight in kg: | 0,097 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
