Product information "0199 22 27 Single banjo elbow connection"
Single banjo elbow connection between tube and male thread. Can be aligned in the desired position. Available from 4 to 28 mm o.d. and BSPT or NPT thread.
Weight in kg:
0,387
Maximum working pressure in bar:
550
max. temperature in °C:
250
min. temperature in °C:
-60
RoHS compliant:
Yes
Material seal:
NBR
Material body:
Brass
Material gripping ring:
Brass
Material union nut:
Brass
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
