The standard range offers a robust construction and a good compromise between size and flow performance.
• Robust construction - perfect solution for demanding applications
• Nickel-plated brass for corrosion resistance
• Robust construction - perfect solution for demanding applications
• Nickel-plated brass for corrosion resistance
| Series: | Standard |
| Flow rate in l/min: | 480 (air) |
| Material connection: | Galvanized steel |
| Series long: | Standard |
| Working temperature: | -20°C to +80°C (NBR) |
| Surface: | zinc plated |
| Shut-Off: | Plug Straight-Through |
| Connection: | Hose barb 4mm LW(3/16") |
| Material sleeve: | Galvanized steel |
| Connection type: | Hose barb |
| Connection tube outside diameter 2: | 4 |
| Connection tube outside diameter 3: | 6 |
| Bore in mm: | 5 |
| Maximum working pressure in bar: | 20 |
| Material: | Galvanized steel |
| RoHS compliant: | Yes |
| Weight in kg: | 0,014 |
All information is intended as a non-binding guideline! We do not assume liability for any data selection not confirmed in writing.
